9906683 Horton DM Advantage Fan Clutch Rebuild Kit - Heavy Duty Dual Bearing - Freightliner / Peterbilt / Kenworth

Heavy Duty Fan Clutch Rebuild Kit - Replaces Horton 9906683

Don't spend $1,500 on a new fan clutch. Rebuild yours in 30 minutes with this Heavy Duty Kit.

The Problem

Your fan clutch is slipping, leaking air, or the bearing has seized. The engine is overheating on grades, the fan won't engage, or it runs at full speed all the time. The dealer wants to sell you a completely new hub assembly for $1,400–$1,800. But the failure point is almost always just the Seals — not the entire clutch.

The Solution

This heavy-duty rebuild kit replaces ALL the wear parts in your Horton DM Advantage clutch with upgraded components. New friction seals — everything that actually wears out. The kit uses dual-row bearings that are stronger than the original single-bearing Horton design, giving you longer service life. The high-torque spring pack ensures the fan stays engaged when you need it. Replaces Horton part number 9906683.

What's In The Kit

• Friction Liner: Heavy-duty replacement liner — direct fit for the DM Advantage clutch face
• Air Cartridge: New pneumatic cartridge for positive engagement
• Dual-Row Bearings: Upgraded from the OEM single-row design for superior load capacity and longer life
• Spring Pack: High-torque springs for reliable fan engagement under load
• All Hardware: Everything needed for a complete rebuild

Technical Upgrade

• Replaces: Horton 9906683, 9801546
• Upgrade: Features dual-row bearings for longer life (OEM uses single row)
• Torque: High-torque spring pack ensures the fan stays engaged when you need it

Compatible Equipment

This rebuild kit fits all trucks and equipment using the Horton DM Advantage (DriveMaster) 2-Speed fan clutch:

Freightliner

• Freightliner Cascadia (Cummins ISX / Detroit DD13 / DD15 / DD16)
• Freightliner Columbia (Cummins ISX / Detroit Series 60)
• Freightliner Century (Cummins ISX / Detroit Series 60)
• Freightliner Coronado (Cummins ISX / CAT C15)

Peterbilt

• Peterbilt 579 (PACCAR MX-13 / Cummins ISX)
• Peterbilt 389 (Cummins ISX / CAT C15)
• Peterbilt 567 (PACCAR MX-13 / Cummins ISX)
• Peterbilt 367 (Cummins ISX / CAT C15)

Kenworth

• Kenworth T680 (PACCAR MX-13 / Cummins ISX)
• Kenworth T880 (PACCAR MX-13 / Cummins ISX)
• Kenworth W900 (Cummins ISX / CAT C15)
• Kenworth T800 (Cummins ISX / CAT C15)

Volvo / Mack

• Volvo VNL (Volvo D13)
• Mack Anthem / Pinnacle (Volvo D13)

Heavy Equipment

• Large excavators, wheel loaders, and off-highway trucks using Horton DM Advantage pneumatic fan clutches

Look for the Horton logo on the front face of your fan clutch. If it says "DM Advantage" or "DriveMaster" and your parts book references 9906683, this is the correct kit.

Why Rebuild Instead of Replace?

• Save $600–$900: A new Horton DM Advantage clutch assembly costs $1,400–$1,800 from the dealer. This rebuild kit restores your existing clutch to like-new condition for a fraction of the cost.
• Stronger Than Original: This is NOT a cheap repair. The dual-row bearings in this kit are actually stronger than the factory single-bearing design. You're upgrading your clutch, not just patching it.
• 30-Minute Install: Remove the clutch from the water pump hub, swap the wear parts, reassemble, and reinstall. A competent mechanic can do it in 30 minutes.
• Machine Down = Money Lost: An overheating engine shuts down the entire truck. Every day your rig sits costs $500–$1,000+ in lost revenue. Get this kit, rebuild it, and get back to work.
• Fast Shipping: In stock and ready to ship. No waiting weeks on a dealer backorder for a complete assembly.

Installation Notes

When rebuilding with this kit:

• Remove the fan clutch assembly from the water pump hub
• Disassemble the clutch pack — note orientation of all components
• Clean the housing thoroughly — carbon dust and debris must be removed
• Install new friction liner, air cartridge, bearings, and springs per kit instructions
• Reassemble and torque all fasteners to spec
• Reinstall on the water pump hub
• Test fan engagement — verify the fan engages with air pressure (90+ PSI) and disengages cleanly
• Check for air leaks at the air line connections

Frequently Asked Questions

Will this kit fix my overheating problem?
If the overheating is caused by a slipping or seized fan clutch, yes. The most common failure mode on the Horton DM Advantage is worn friction material and failed bearings — exactly what this kit replaces. However, if the overheating is caused by a plugged radiator, failed water pump, or blown head gasket, the fan clutch may not be your issue.

Is this kit as reliable as a brand-new Horton clutch?
Yes — and in one key area, it's actually better. The dual-row bearings in this kit have higher load capacity than the OEM single-row bearing used in the original Horton design. The friction material and air cartridge are equivalent to OEM spec. You're getting OEM-equivalent or better performance at a fraction of the cost.

How do I know if my fan clutch needs to be rebuilt?
Common symptoms: engine overheats on grades or under load, fan doesn't engage when it should, fan runs at full speed all the time (seized bearing), air leaking from the clutch body, or visible wobble in the fan assembly (worn bearing). If you hear a grinding noise from the front of the engine, the bearing is failing and a rebuild is urgent.

What if my clutch housing is cracked or damaged?
This kit replaces the internal wear components — friction liner, bearings, air cartridge, and springs. If the outer housing or hub body is cracked, gouged, or warped, you'll need a complete replacement assembly. Inspect the housing carefully before ordering.
